CTEs and UNIONs, Wrap it up!

CTEs (Common Table Expressions) can solve a lot of performance issues.  Maybe not all of them, but a majority of them.





I ran into a situation recently that was quite frustrating.  A customer I was working with had created a rather large and complex CTE that was 3 select statements with the UNION ALL operation pulling them together.  I’m a huge fan of the /*+ MATERIALIZE */ hint for CTEs as this will keep the CTE as a separate entity.   Using this hint more times than not is best for performance.





But this CTE wouldn’t get materialized.  It was in effect ignoring the hint.





Turns out a CTE using UNION or UNION ALL will do this.  I didn’t find any official documentation on this, given that the MATERIALIZE hint is really undocumented anyway, this is not a surprise.





A solution I found was to “wrap it” in another select.





Here is an example query to illustrate the technique.  Yes, this is a silly query but it works for showing what I’m talking about.





WITH loc_cte AS (

    SELECT /*+ MATERIALIZE */

        ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'NEW YORK'

    UNION

    SELECT

        ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'DALLAS'

    UNION

    SELECT

         ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'CHICAGO'

)

SELECT ename, sal, dname FROM loc_cte

ORDER BY sal, ename;





For this one the explain plan looks like below.  Notice there is not a materialized object for the CTE, the main query and the CTE have been merged together.  There are remnants of the CTE in here, but key is that the CTE is not being materialized. (The focus here is not what the optimizer did when it transformed the query. Maybe a topic for another day.)





--------------------------------------------------------------------------------------------

| Id  | Operation                          | Name               | Rows  | Bytes | Time     |

--------------------------------------------------------------------------------------------

|   0 | SELECT STATEMENT                   |                    |    12 |   348 | 00:00:01 |

|   1 |  SORT ORDER BY                     |                    |    12 |   348 | 00:00:01 |

|   2 |   VIEW                             |                    |    12 |   348 | 00:00:01 |

|   3 |    SORT UNIQUE                     |                    |    12 |   414 | 00:00:01 |

|   4 |     UNION-ALL                      |                    |       |       |          |

|   5 |      NESTED LOOPS                  |                    |     3 |    99 | 00:00:01 |

|   6 |       NESTED LOOPS                 |                    |     5 |    99 | 00:00:01 |

|*  7 |        TABLE ACCESS STORAGE FULL   | DEPT               |     1 |    20 | 00:00:01 |

|*  8 |        INDEX RANGE SCAN            | EMP_DEPT_IDX       |     5 |       | 00:00:01 |

|   9 |       TABLE ACCESS BY INDEX ROWID  | EMP                |     3 |    39 | 00:00:01 |

|  10 |      NESTED LOOPS                  |                    |     9 |   315 | 00:00:01 |

|  11 |       NESTED LOOPS                 |                    |    10 |   315 | 00:00:01 |

|  12 |        VIEW                        | VW_JF_SET$5E11AB46 |     2 |    44 | 00:00:01 |

|  13 |         SORT UNIQUE                |                    |     2 |    40 | 00:00:01 |

|  14 |          UNION-ALL                 |                    |       |       |          |

|* 15 |           TABLE ACCESS STORAGE FULL| DEPT               |     1 |    20 | 00:00:01 |

|* 16 |           TABLE ACCESS STORAGE FULL| DEPT               |     1 |    20 | 00:00:01 |

|* 17 |        INDEX RANGE SCAN            | EMP_DEPT_IDX       |     5 |       | 00:00:01 |

|  18 |       TABLE ACCESS BY INDEX ROWID  | EMP                |     4 |    52 | 00:00:01 |

--------------------------------------------------------------------------------------------







Now the change to the plan is to wrap the CTE in a select.  I’d recommend you don’t use SELECT * for the wrapping select.  I’m not a fan of this syntax as it can cause problems.





WITH loc_cte AS (

    select /*+ MATERIALIZE */ ename, sal, dname from (

    SELECT

        ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'NEW YORK'

    UNION

    SELECT

        ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'DALLAS'

    UNION

    SELECT

         ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'CHICAGO'

))

SELECT ename, sal, dname FROM loc_cte

ORDER BY sal, ename;





And now the plan shows the CTE staying as a separate entity (it’s been materialized, Beam me up Scotty!).





-----------------------------------------------------------------------------------------------------------

| Id  | Operation                                | Name                        | Rows  | Bytes | Time     |

-----------------------------------------------------------------------------------------------------------

|   0 | SELECT STATEMENT                         |                             |    12 |   348 | 00:00:01 |

|   1 |  TEMP TABLE TRANSFORMATION               |                             |       |       |          |

|   2 |   LOAD AS SELECT (CURSOR DURATION MEMORY)| SYS_TEMP_3FD9E6966_7A9C9340 |       |       |          |

|   3 |    VIEW                                  |                             |    12 |   348 | 00:00:01 |

|   4 |     SORT UNIQUE                          |                             |    12 |   828 | 00:00:01 |

|   5 |      UNION-ALL                           |                             |       |       |          |

|   6 |       NESTED LOOPS                       |                             |     3 |    99 | 00:00:01 |

|   7 |        NESTED LOOPS                      |                             |     5 |    99 | 00:00:01 |

|*  8 |         TABLE ACCESS STORAGE FULL        | DEPT                        |     1 |    20 | 00:00:01 |

|*  9 |         INDEX RANGE SCAN                 | EMP_DEPT_IDX                |     5 |       | 00:00:01 |

|  10 |        TABLE ACCESS BY INDEX ROWID       | EMP                         |     3 |    39 | 00:00:01 |

|  11 |       NESTED LOOPS                       |                             |     9 |   315 | 00:00:01 |

|  12 |        NESTED LOOPS                      |                             |    10 |   315 | 00:00:01 |

|  13 |         VIEW                             | VW_JF_SET$B1ADC4B5          |     2 |    44 | 00:00:01 |

|  14 |          SORT UNIQUE                     |                             |     2 |    80 | 00:00:01 |

|  15 |           UNION-ALL                      |                             |       |       |          |

|* 16 |            TABLE ACCESS STORAGE FULL     | DEPT                        |     1 |    20 | 00:00:01 |

|* 17 |            TABLE ACCESS STORAGE FULL     | DEPT                        |     1 |    20 | 00:00:01 |

|* 18 |         INDEX RANGE SCAN                 | EMP_DEPT_IDX                |     5 |       | 00:00:01 |

|  19 |        TABLE ACCESS BY INDEX ROWID       | EMP                         |     4 |    52 | 00:00:01 |

|  20 |   SORT ORDER BY                          |                             |    12 |   348 | 00:00:01 |

|  21 |    VIEW                                  |                             |    12 |   348 | 00:00:01 |

|  22 |     TABLE ACCESS STORAGE FULL            | SYS_TEMP_3FD9E6966_7A9C9340 |    12 |   348 | 00:00:01 |

-----------------------------------------------------------------------------------------------------------





And there you have it!  Here is the full script if you’d like to run it on your own.  Enjoy!





explain plan for

WITH loc_cte AS (

    SELECT /*+ MATERIALIZE */

        ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'NEW YORK'

    UNION

    SELECT

        ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'DALLAS'

    UNION

    SELECT

         ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'CHICAGO'

)

SELECT ename, sal, dname FROM loc_cte

ORDER BY sal, ename;



set lines 4000

set pages 5000

select * from table(DBMS_XPLAN.display(format=>'advanced -cost -projection'));





explain plan for

WITH loc_cte AS (

    select /*+ MATERIALIZE */ ename, sal, dname from (

    SELECT

        ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'NEW YORK'

    UNION

    SELECT

        ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'DALLAS'

    UNION

    SELECT

         ename, sal, dname

    FROM

        emp, dept

    WHERE

            emp.deptno = dept.deptno

        AND dept.loc = 'CHICAGO'

))

SELECT ename, sal, dname FROM loc_cte

ORDER BY sal, ename;



set lines 4000

set pages 5000

select * from table(DBMS_XPLAN.display(format=>'advanced -cost -projection'));

Using the MATERIALIZE hint correctly

 I see queries like this from time to time:



SELECT /*+ materialize */ * FROM (SELECT bla-bla-bla…);



I’m pretty sure that the  MATERIALIZE hint is doing nothing when used in this way.  The MATERIALIZE hint is for CTEs (common table expressions) crated using the WITH clause.  I am unable to see what is does for any other use.  If someone can send me a repeatable test case that I can run showing it does something in other cases I’m open to being proven wrong.



This is the type of statement where the hint works as expected.  This creates a structure that is similar to a Global Temp Table, this structure is dropped after the statement completes.



WITH emp_dept_cte AS (

    SELECT /*+ materialize */ empno, sal, dname

    FROM

        emp,dept

    WHERE

        emp.deptno = dept.deptno

)

SELECT * FROM emp_dept_cte;



But it doesn’t work when I write something like this:



Select /*+ materialize */  * from (SELECT empno, sal, dname

    FROM

        emp, dept

    WHERE

        emp.deptno = dept.deptno )



In this query no matter where I put the MATERIALIZE hint, no temp table like object is created and used.

In the plan for the first query above I can clearly see the temp table being created in the auto trace with the step LOAD AS SELECT and an object name that starts with SYS_TEMP_ followed by an apparent random combination of numbers and letters. (I’m pretty sure it’s a hexadecimal number for the internal object.)



Using the MATERLIZE hint when not using the WITH clause, I do not see this step in the plan.  Hence no temp table like structure.





Have a great day!





Optimizing your SQL starts before you write any code

 Writing good SQL is more about how you think than what you write.  The problem that most of us have is that we think in terms of individual rows when we really need to think more in terms of sets of rows.





Of course, this is natural for us to do since the end product is the individual rows, and we don’t necessarily think of them as a set.  But they are.  They are a set that satisfies the conditions that the business defines for the data they want.





 We need to think this way always when writing and optimizing our SQL.  Too often we write code that is very much “row-by-row” (or as Tome Kyte would say “row-by-slow”).  The classic example is the correlated subquery in the SELECT list.  This will return a row for each row defined by the calling (outer) query.  The optimizer has a neat trick called subquery caching where it will cache values for “repeating” values coming into it.  That is great and the subquery can run less frequently.





However, this isn’t always possible. If the values being passed in are relatively unique the saving by this can be minimal, and if totally unique it doesn’t help at all.  Also, it only can cache so many values (version dependent) and there is a problem of HASH collisions as it uses a hash algorithm to store the values in a hash table.   Bottom line, don’t count on this to save your performance.





Better to not have correlated subqueries in the select list.  Of course, ones that run for a very few distinct values can be fine.  What I talking about is the ones that run thousands or millions of times.  Just making these run faster isn’t really solving the problem either, you’re just kicking the can down the road.  As the data volume increases (and it always does) this will eventually not be fast enough.





I’m a huge fan of CTEs (Common Table Expressions).  I’ve written several posts about these.  In my experience CTEs can solve something like 80% of performance problems.   And for the correlated subquery they are the best solution.





This is also thinking  in terms of sets of rows (values), not one at a time.  For that correlated subquery, how can I get all the possible values I would need for the subquery all at once and not one at a time?  The CTE is the perfect solution.   This isn’t the only way they can be used to help performance, but it is one of the most powerful.
