Friday, October 12, 2018

Clusters in the cloud or not

Many folks are familiar with the single table hash cluster in Oracle land.  However there are really two kinds of clusters in Oracle land, Index and Hash.  Both are rarely used these days and have their roots way back in Oracle time when these were the only other alternative to a POT (Plain Old Table).   Should you use them?  Most likely no, I’ll talk about them and show you why not.

The index cluster is a way to pre-join table data.  This is also the default type of cluster.  It’s a multi-step process; you first create the cluster, then the tables in the cluster, then the index on the cluster key.   What happens at the block level is that data of the same cluster key are stored together. The main point here is that unlike a POT, data from the set of tables are stored together in the same block.  (Typically there will be two tables in an index cluster but you can have more.)

Using the classic example for the good old EMP and DEPT tables if you were to create a cluster for these you’d use DEPTNO as the cluster key.   Then create each table in the cluster.  Now the table data for a matching department number in both tables are stored together in the same data block.  Note that the cluster is now the storage segment, not the tables.

On the surface this can seem like a great thing, and it is provided you always retrieve the data in the joined state.  But what if you access the tables independently?  Keep in mind they are literally stored together in the same data blocks.  This means that to get either table, you are scanning blocks that contain data from both tables.   In a typical parent-child table relationship, the parent table has far fewer rows then the child.  Hence to get a set of parent rows you may end having to go thru 100s or 1,000s of blocks to find a relatively small amount of data.

Some other issues are modifying the cluster key is more expensive than if the table were not clustered.  If the data from the set of tables with the same key will occupy more than about 2 blocks, they you’re likely better off not clustering the tables.  Also if the number of matching rows per key is very different, the cluster will likely have a lot of wasted space in it.  Any block in the cluster will only have rows with one cluster key in it; hence you could have some blocks with very few rows in them.

 So should you use them?  Personally every time I tried to use them, the issues mentioned above ended up forcing us to go back to POTs.  But if you always return the data in the joined form then they can be helpful in reducing IO since you could get data from all the tables with very few LIOs.

Now how about them Hash clusters?  They too can have more than one table in it.   It’s the same basic technique, create the cluster, and put the tables into it.  You don’t have to create an index on the key. You can if you want to, but the idea of using a hash key is to not have an index on it.  This time Oracle stores data in the same block that has the same hash value.   Again if you retrieve the data from the set of tables joining on the hash key this is good.

These are popular as Single Table Hash Clusters, which are very cool because they allow you to get a row with two IO operations pretty much no matter how big the table is.   With small tables this is easily achievable with an index.  However as soon as the index grows and has two or more levels, the LIOs will increase with the levels of the index.

To create these you have to use the clause “SINGLE TABLE HASHKEYS N” where N is a positive value.  This is the number of expected hash keys there will be in the table.  This number is round up to the nearest prime number.  Warning: Unlike a POT, Oracle will immediately allocate the space needed for all the HASHKEYS; hence a large number will allocate a lot of space right away.  Of course if you need this then all is good, just be aware that it’s allocating all the space up front.   Optionally you can also specify a SIZE parameter; this is the amount of space reserved for all rows with the same hash key.  If not specified, then one data block is allocated for each key.

Also you can even define the hash algorithm used to hash the values. If you don’t Oracle uses one to hash them.   This does give you a lot of control over how the data is stored and you can even predict the number of keys that will hash to the same value if you define it.

The best use of a single table hash cluster is looking up rows by the hash key using an equality predicate.  You’ll see the access of the table as “TABLE ACCESS HASH”.  Even when you retrieve a set of rows (when the hash key is not unique) this will likely have a few LIOs.

Here is a set of test queries that shows the good and bad of single table hash clusters.  This test is using a table ORD2 a POT and ORD2_HASH in a single table hash cluster.   The script is below; I’ll just show the output here.

These tests are running this query which will retrieve a count of 20 rows:
select count(*) into x1 from [TABLE] where cust_no = 32076;
......................................................
selecting from ORD2 10000 times a POT
......................................................
In hundredths of a second
**** TIME - 524
**** CPU  - 524
**** LIO  - 1910000
......................................................
selecting from ORD2 10000 times a POT with index
......................................................
In hundredths of a second
**** TIME - 53
**** CPU  - 50
**** LIO  - 20000

......................................................
selecting from ORD2_HASH 10000 times a single table hash cluster
......................................................
In hundredths of a second
**** TIME - 47
**** CPU  - 45
**** LIO  - 10079

What you can see in this first set of tests that the single table hash cluster beat out the POT even when it had an index on the column.  So this is looking good for the single table hash cluster.  Now let’s see how things go with a range scan.

These tests are running this query which will retrieve a count of 26 rows:
select count(*) into x1 from [TABLE] where cust_no between 32076 and 32080;
......................................................
range scan from ORD2 10000 times a POT with index
......................................................
In hundredths of a second
**** TIME - 50
**** CPU  - 50
**** LIO  - 20000

......................................................
range scan from ORD2_HASH 10000 times a single table hash cluster
......................................................
In hundredths of a second
**** TIME - 1273
**** CPU  - 1265
**** LIO  - 3170067

......................................................
range scan from ORD2_HASH 10000 times a single table hash cluster with index
......................................................
In hundredths of a second
**** TIME - 53
**** CPU  - 51
**** LIO  - 20014

Here you can see the single table hash cluster really doesn’t help.  Without an index on the column it reverts to a full table scan.  With an index it’s really the same as the POT with an index (the extra LIOs and time are from the parsing of the statement because of the new index).  Is that really worth it?  Of course that is a question only you can answer for your environment.

As you might guess most of the issues with index clusters are still there with hash clusters.  A hash cluster is likely not a good choice is where the hash key is updated.  This will require the row to move (most likely) and will in effect cause a delete/insert like activity which will be slower than just updating the field.   Doing full table scans on tables in a hash cluster will likely be longer, since Oracle only stores data in a block with the same hash value, there is likely to be blocks with only a few rows in them.   And it’s really important to use equality predicates when accessing the hash key.  Other types of predicates will tend to drive full scans as seen above.   Yes you can have an index on the column, but the basic idea of using a cluster is to not use an index.  Because if you’re going to use an index, than you’re likely better off with just a POT with and index.

What you should glen from this is that you pretty much have to know the size of the data you’ll be using in the single hash table.  You need to know the number of rows that will hash to the same value (the HASHKEYS) and how big that total set of rows will be (the SIZE).  Using a single table hash cluster is not likely to work optimally when these are not known.  You don’t necessarily have to be precise with these values, but you should be close and likely over estimate a bit.  The issue here is if you under estimate to much then over flow blocks get created and you start to lose the advantage of the hashing.  In which case your performance is likely back to what a POT and indexing would have been, maybe worse.

What’s the bottom line?  Using clusters is cool and they do work well for very specific usages.  If you wander outside these usages then they will likely not help and may even hurt performance.


Here is the script I used for the tests show above.  The script to create the ORD2 table is a bit too big to put in here as a blog post.  If you’d like it please contact me ric.van.dyke at hotsos dot com and I can send it to you.

rem testing selecting from a POT vs a single table hash cluster
rem OCT2018  RVD
rem
set echo on feedback on serveroutput on
drop index ord2_cust_no;
drop index ord2h_cust_no;
drop table ord2_hash;
drop cluster cust_orders;

CREATE CLUSTER cust_orders (cust_id NUMBER(*,0))
SINGLE TABLE HASHKEYS 200;

create table ord2_hash
cluster cust_orders(cust_no)
as select * from ord2;

declare
    x1           number;
    l_start_time pls_integer;
    l_start_cpu  pls_integer;
    l_start_cr   pls_integer :=0;
    l_end_cr     pls_integer :=0;
begin
    select value into l_start_cr from v$mystat where STATISTIC# = 139;
    l_start_time := DBMS_UTILITY.GET_TIME;
    l_start_cpu  := DBMS_UTILITY.GET_CPU_TIME;
    for ii in 1 .. 10000 loop
           select count(*) into x1 from ord2 where cust_no = 32076;
    end loop;
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('selecting from ORD2 10000 times a POT');
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('In hundredths of a second');
    DBMS_OUTPUT.put_line ('**** TIME - '||to_char(DBMS_UTILITY.GET_TIME - l_start_time));
    DBMS_OUTPUT.put_line ('**** CPU  - '||to_char(DBMS_UTILITY.GET_CPU_TIME - l_start_cpu));
    select value into l_end_cr from v$mystat where STATISTIC# = 139;
    DBMS_OUTPUT.put_line ('**** LIO  - '||to_char( l_end_cr - l_start_cr));
end;
/

create index ord2_cust_no on ord2(cust_no);

declare
    x1           number;
    l_start_time pls_integer;
    l_start_cpu  pls_integer;
    l_start_cr   pls_integer :=0;
    l_end_cr     pls_integer :=0;
begin
    select value into l_start_cr from v$mystat where STATISTIC# = 139;
    l_start_time := DBMS_UTILITY.GET_TIME;
    l_start_cpu  := DBMS_UTILITY.GET_CPU_TIME;
    for ii in 1 .. 10000 loop
           select count(*) into x1 from ord2 where cust_no = 32076;
    end loop;
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('selecting from ORD2 10000 times a POT with index');
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('In hundredths of a second');
    DBMS_OUTPUT.put_line ('**** TIME - '||to_char(DBMS_UTILITY.GET_TIME - l_start_time));
    DBMS_OUTPUT.put_line ('**** CPU  - '||to_char(DBMS_UTILITY.GET_CPU_TIME - l_start_cpu));
    select value into l_end_cr from v$mystat where STATISTIC# = 139;
    DBMS_OUTPUT.put_line ('**** LIO  - '||to_char( l_end_cr - l_start_cr));
end;
/


declare
    x1           number;
    l_start_time pls_integer;
    l_start_cpu  pls_integer;
    l_start_cr   pls_integer :=0;
    l_end_cr     pls_integer :=0;
begin
    select value into l_start_cr from v$mystat where STATISTIC# = 139;
    l_start_time := DBMS_UTILITY.GET_TIME;
    l_start_cpu  := DBMS_UTILITY.GET_CPU_TIME;
    for ii in 1 .. 10000 loop
           select count(*) into x1 from ord2_hash where cust_no = 32076;
    end loop;
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('selecting from ORD2_HASH 10000 times a single table hash cluster');
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('In hundredths of a second');
    DBMS_OUTPUT.put_line ('**** TIME - '||to_char(DBMS_UTILITY.GET_TIME - l_start_time));
    DBMS_OUTPUT.put_line ('**** CPU  - '||to_char(DBMS_UTILITY.GET_CPU_TIME - l_start_cpu));
    select value into l_end_cr from v$mystat where STATISTIC# = 139;
    DBMS_OUTPUT.put_line ('**** LIO  - '||to_char( l_end_cr - l_start_cr));
end;
/

rem now doing a range scan leaving the index in place on ORD2 for CUST_NO
rem but no index on ORD2_HASH for CUST_NO

declare
    x1           number;
    l_start_time pls_integer;
    l_start_cpu  pls_integer;
    l_start_cr   pls_integer :=0;
    l_end_cr     pls_integer :=0;
begin
    select value into l_start_cr from v$mystat where STATISTIC# = 139;
    l_start_time := DBMS_UTILITY.GET_TIME;
    l_start_cpu  := DBMS_UTILITY.GET_CPU_TIME;
    for ii in 1 .. 10000 loop
           select count(*) into x1 from ord2 where cust_no between 32076 and 32080;
    end loop;
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('range scan from ORD2 10000 times a POT with index');
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('In hundredths of a second');
    DBMS_OUTPUT.put_line ('**** TIME - '||to_char(DBMS_UTILITY.GET_TIME - l_start_time));
    DBMS_OUTPUT.put_line ('**** CPU  - '||to_char(DBMS_UTILITY.GET_CPU_TIME - l_start_cpu));
    select value into l_end_cr from v$mystat where STATISTIC# = 139;
    DBMS_OUTPUT.put_line ('**** LIO  - '||to_char( l_end_cr - l_start_cr));
end;
/


declare
    x1           number;
    l_start_time pls_integer;
    l_start_cpu  pls_integer;
    l_start_cr   pls_integer :=0;
    l_end_cr     pls_integer :=0;
begin
    select value into l_start_cr from v$mystat where STATISTIC# = 139;
    l_start_time := DBMS_UTILITY.GET_TIME;
    l_start_cpu  := DBMS_UTILITY.GET_CPU_TIME;
    for ii in 1 .. 10000 loop
           select count(*) into x1 from ord2_hash where cust_no between 32076 and 32080;
    end loop;
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('range scan from ORD2_HASH 10000 times a single table hash cluster');
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('In hundredths of a second');
    DBMS_OUTPUT.put_line ('**** TIME - '||to_char(DBMS_UTILITY.GET_TIME - l_start_time));
    DBMS_OUTPUT.put_line ('**** CPU  - '||to_char(DBMS_UTILITY.GET_CPU_TIME - l_start_cpu));
    select value into l_end_cr from v$mystat where STATISTIC# = 139;
    DBMS_OUTPUT.put_line ('**** LIO  - '||to_char( l_end_cr - l_start_cr));
end;
/

rem lastly put an index on ORD2_HASH.CUST_NO

create index ord2h_cust_no on ORD2_HASH(CUST_NO);

declare
    x1           number;
    l_start_time pls_integer;
    l_start_cpu  pls_integer;
    l_start_cr   pls_integer :=0;
    l_end_cr     pls_integer :=0;
begin
    select value into l_start_cr from v$mystat where STATISTIC# = 139;
    l_start_time := DBMS_UTILITY.GET_TIME;
    l_start_cpu  := DBMS_UTILITY.GET_CPU_TIME;
    for ii in 1 .. 10000 loop
           select count(*) into x1 from ord2_hash where cust_no between 32076 and 32080;
    end loop;
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('range scan from ORD2_HASH 10000 times a single table hash cluster with index');
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('In hundredths of a second');
    DBMS_OUTPUT.put_line ('**** TIME - '||to_char(DBMS_UTILITY.GET_TIME - l_start_time));
    DBMS_OUTPUT.put_line ('**** CPU  - '||to_char(DBMS_UTILITY.GET_CPU_TIME - l_start_cpu));
    select value into l_end_cr from v$mystat where STATISTIC# = 139;
    DBMS_OUTPUT.put_line ('**** LIO  - '||to_char( l_end_cr - l_start_cr));
end;
/

Friday, September 28, 2018

One row to rule them all in the cloud or not


Looking for a single row out of a table it’s always better to use an index and a unique is best.  Yes even for a small table.  As a test of this I have a table that has 10 rows in it and just two columns, a number and a sting of 20 random characters.   I’ll run a select in a loop that gets each row one at a time using the number column which will be unique, 1 to 10.  I’ll do this 100,000 times and capture both elapsed time and CPU time.  Also I’ll capture the number for consistent gets (LIOs) done for each.

The first go around it will be without an index, with an index, with a unique index and last with a unique covering index.  Here is how it stacked up in my test (I ran the test multiple times and the results were consistent):

......................................................
selecting all 10 rows without an index 100000 times
......................................................
In hundredths of a second
**** TIME - 5669
**** CPU  - 5629
**** LIO  - 7000020

......................................................
selecting all 10 rows with an index 100000 times
......................................................
In hundredths of a second
**** TIME - 4883
**** CPU  - 4852
**** LIO  - 2000011

......................................................
selecting all 10 rows with a unique index 100000 times
......................................................
In hundredths of a second
**** TIME - 4556
**** CPU  - 4536
**** LIO  - 2000004

......................................................
selecting all 10 rows with a unique covering index 100000 times
......................................................
In hundredths of a second
**** TIME - 4516
**** CPU  - 4482
**** LIO  - 1000014

Well there it is.  Over all everything got better as the test went from the no index to index and then to unique index.   The full table scan used for the first query did about seven LIOs per execution, it’s a five block table plus the header block which gets visited twice each scan.  The data of the table fits in one block, but the high water mark is at five.  A full table scan always scans to the high water mark, so we get five LIOs for the table scan.

For the first two index scans there are about two LIOs per execution, one in the index and one in the table.   The entire index is in one index block, which gets the ROWID and then the scan into the table goes to just the one block where the data is.

The LIOs are not really that much different when it used the unique index but it was faster, why?  A key here is the latching protocol used.   With a unique index oracle is able to use a lighter weight latching protocol  (consistent gets examination) when accessing the index, this ends up taking less time than just using a non-unique index which uses the normal latching protocol (consistent gets).

The last query used a covering index; this index had both columns of the table in it.  The time is better, not by much, but it’s now down to just one LIO per access.  This is because it just goes to the index and gets everything and never even goes to the table.   By only doing one LIO is really best, this has the best scalability and the lest possible latch contention.   (Also you could use an IOT (Index Organized Table) which would be the same.)

So it is very true that looking up a single row is really faster with an index and best with a unique index even on a 10 row table.  It might not seem like much but doing it thousands or millions of time, the saving will start to make a difference.

Note:  There are some “extra” LIOs when the queries run, most of which are likely caused by any parsing going on.

Here is the code for the test if you’d like to try it yourself:

rem testing to get one row out of a table.
rem SEP2018  RVD
rem
set echo on feedback on serveroutput on
drop table iamsmall purge;
create table iamsmall (id_col number, data_col varchar(20));
begin
 for x in 1..10 loop
   insert into iamsmall values (x, (dbms_random.string('A',20)));
 end loop;
end;
/

declare
    x1           varchar2(20);
    l_start_time pls_integer;
    l_start_cpu  pls_integer;
    l_start_cr   pls_integer :=0;
    l_end_cr     pls_integer :=0;
begin
    select value into l_start_cr from v$mystat where STATISTIC# = 139;
    l_start_time := DBMS_UTILITY.GET_TIME;
    l_start_cpu  := DBMS_UTILITY.GET_CPU_TIME;
    for ii in 1 .. 100000 loop
     for i in 1 .. 10 loop
        select data_col into x1 from iamsmall where id_col = i;
     end loop;
    end loop;
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('selecting all 10 rows without an index 100000 times');
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('In hundredths of a second');
    DBMS_OUTPUT.put_line ('**** TIME - '||to_char(DBMS_UTILITY.GET_TIME - l_start_time));
    DBMS_OUTPUT.put_line ('**** CPU  - '||to_char(DBMS_UTILITY.GET_CPU_TIME - l_start_cpu));
    select value into l_end_cr from v$mystat where STATISTIC# = 139;
    DBMS_OUTPUT.put_line ('**** LIO  - '||to_char( l_end_cr - l_start_cr));
end;
/

rem create a nonunique index on id_col
create index ias_id on iamsmall(id_col);
declare
    x1           varchar2(20);
    l_start_time pls_integer;
    l_start_cpu  pls_integer;
    l_start_cr   pls_integer :=0;
    l_end_cr     pls_integer :=0;
begin
    select value into l_start_cr from v$mystat where STATISTIC# = 139;
    l_start_time := DBMS_UTILITY.GET_TIME;
    l_start_cpu  := DBMS_UTILITY.GET_CPU_TIME;
    for ii in 1 .. 100000 loop
     for i in 1 .. 10 loop
        select data_col into x1 from iamsmall where id_col = i;
     end loop;
    end loop;
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('selecting all 10 rows with an index 100000 times');
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('In hundredths of a second');
    DBMS_OUTPUT.put_line ('**** TIME - '||to_char(DBMS_UTILITY.GET_TIME - l_start_time));
    DBMS_OUTPUT.put_line ('**** CPU  - '||to_char(DBMS_UTILITY.GET_CPU_TIME - l_start_cpu));
    select value into l_end_cr from v$mystat where STATISTIC# = 139;
    DBMS_OUTPUT.put_line ('**** LIO  - '||to_char( l_end_cr - l_start_cr));
end;
/

rem create a unique index on id_col
drop index ias_id;
create unique index ias_id on iamsmall(id_col);
declare
    x1           varchar2(20);
    l_start_time pls_integer;
    l_start_cpu  pls_integer;
    l_start_cr   pls_integer :=0;
    l_end_cr     pls_integer :=0;
begin
    select value into l_start_cr from v$mystat where STATISTIC# = 139;
    l_start_time := DBMS_UTILITY.GET_TIME;
    l_start_cpu  := DBMS_UTILITY.GET_CPU_TIME;
    for ii in 1 .. 100000 loop
     for i in 1 .. 10 loop
        select data_col into x1 from iamsmall where id_col = i;
     end loop;
    end loop;
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('selecting all 10 rows with a unique index 100000 times');
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('In hundredths of a second');
    DBMS_OUTPUT.put_line ('**** TIME - '||to_char(DBMS_UTILITY.GET_TIME - l_start_time));
    DBMS_OUTPUT.put_line ('**** CPU  - '||to_char(DBMS_UTILITY.GET_CPU_TIME - l_start_cpu));
    select value into l_end_cr from v$mystat where STATISTIC# = 139;
    DBMS_OUTPUT.put_line ('**** LIO  - '||to_char( l_end_cr - l_start_cr));
end;
/


rem create a unique covering index on id_col,data_col

drop index ias_id;
create unique index ias_id on iamsmall(id_col, data_col);
declare
    x1           varchar2(20);
    l_start_time pls_integer;
    l_start_cpu  pls_integer;
    l_start_cr   pls_integer :=0;
    l_end_cr     pls_integer :=0;
begin
    select value into l_start_cr from v$mystat where STATISTIC# = 139;
    l_start_time := DBMS_UTILITY.GET_TIME;
    l_start_cpu  := DBMS_UTILITY.GET_CPU_TIME;
    for ii in 1 .. 100000 loop
     for i in 1 .. 10 loop
        select data_col into x1 from iamsmall where id_col = i;
     end loop;
    end loop;
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('selecting all 10 rows with a unique covering index 100000 times');
    DBMS_OUTPUT.put_line ('......................................................');
    DBMS_OUTPUT.put_line ('In hundredths of a second');
    DBMS_OUTPUT.put_line ('**** TIME - '||to_char(DBMS_UTILITY.GET_TIME - l_start_time));
    DBMS_OUTPUT.put_line ('**** CPU  - '||to_char(DBMS_UTILITY.GET_CPU_TIME - l_start_cpu));
    select value into l_end_cr from v$mystat where STATISTIC# = 139;
    DBMS_OUTPUT.put_line ('**** LIO  - '||to_char( l_end_cr - l_start_cr));
end;
/
